Metal Detector Kit DIY DC 3V-5V Non-contact Sensing Solder Practice PCB & Parts

৳300 ৳270

0.00/5 See Reviews

SKU : MK0095

Brand : MakersBD

- +
Stock : 24

Specification

  • Kit Name: Simple Metal detector
  • Kit model: MDS-60
  • Standby current:≤5mA
  • Detection depth:≤60 mm
  • Welding difficulty: Easy
  • Working voltage: DC3-5V
  • Working current:≤40mA
  • Detection and alarm mode: sound, light
  • Board size: 86*61mm
  • Material: PVC+ metal

Description

Installation steps:

Step 1: Install metal film resistor R1=200K; R2=2K; R3=470ohm.

Step 2: Install capacitors: C1,C4=104pF; C2,C3=222pf:C5=100uF.

Step 3: Install two S9012s on Q2 and for Q3; Install 1 on Q1

S9018:; Install a potentiometer on VR1.

Step 4: Install the LED with the long foot as the positive pole, corresponding to the square pad mounted on the board.

Step 5: Install the buzzer and power outlet.


Features:

*Brand new and high quality.

*This is a DIY kit that you will need to assemble yourself.

*Made of high quality metal materials,, long service life.

*A perfect DIY metal detector electronics kit for beginners to practice welding.

*Easy to install and uninstall.
