Power Failure Auto Switching Standby Battery Module 5V-48V Universal Emergency Converter YX850

16%

OFF

Power Failure Auto Switching Standby Battery Module 5V-48V Universal Emergency Converter YX850

~~৳220~~ ৳185

0.00/5 See Reviews

SKU : MK0097

Brand : MakersBD

- +

Stock : 23

Contact WhatsApp

Specification
Description
Reviews (0)

Specification

Product Name: Power Failure Automatic Switching Module
Model: YX850
Scope of application: DC5V-48V
Product load: 10A
Product size: 61*30*18mm (length * width * height)
Mounting hole size: 3mm
Installation hole spacing: 23mm
Product weight: about 22g
Connect the DC terminal to the battery for charging when there is power
The charging parameters have nothing to do with this module,but depend on your DC terminal,battery and load.

Description

Be Careful

1. power off for a few tenths of a second during switching.

2. the power supply,battery and load shall have the same voltage.

3. when there is power at the DC end,it is preferred to supply power to the load.

When the DC terminal is powered on,connect the battery for charging (the specific parameters confirmed by yourself have nothing to do with this module)

4. when there is no power at the DC end,the automatic battery will supply power to the load.

Wiring Example
