Type-C 5V Step-Up Boost Lithium Battery Charging and Discharging Protection Board
৳ 220
৳ 149
SKU : MK0499
- Input Interface: Type-C USB port
- Function: Charging and boosting module
- Protection: Overcharge and over-discharge safety
- Output: Stable 5V DC power
- Usage: Ideal for DIY power banks
Home delivery available all over Bangladesh
Standard Delivery
• Inside Dhaka 24 Hours guaranteed delivery.• Outside Dhaka 48 hours guaranteed delivery after order confirmation
Regular Delivery Charge
• Inside Dhaka 60Tk• Outsite Dhaka 120Tk
Cash on Delivery Available
Advance Payment Means Faster Delivery
Download app to enjoy exclusive offers and discounts!
Sold by
MakersBD Gadget & Electronics
Specification
| Specification | Details |
|---|---|
| Item Type | Charging and Boost Protection Board |
| Input Port | Type-C USB |
| Input Voltage | 4.2V-5V DC |
| Output Voltage | 4.2V-24V DC (Boosted) |
| Compatible Battery | 3.7V - 4.2V Lithium Battery |
| Protection Features | Overcharge, Over-discharge, Short Circuit |
| PCB Color | Black |
Description
Product Overview
The Type-C 5V Step-Up Boost Lithium Battery Charging and Discharging Protection Board is an advanced electronic module designed for portable power solutions and DIY battery projects. Combining battery charging and voltage boosting into a single compact circuit board, it simplifies the creation of custom power banks and portable electronics. Crafted with quality surface-mount components, it ensures reliable power delivery and efficient energy conversion for various electronic applications across Bangladesh.
Equipped with a modern Type-C input interface, this module offers seamless connectivity and rapid charging capabilities. Its integrated protection circuitry safeguards lithium-ion and lithium-polymer cells from common electrical hazards, ensuring long battery life and safe operation for everyday hobbyist projects and custom device builds.
Key Features & Advantages
- Dual Functionality: Combines battery charging management and 5V step-up boost output in one compact unit.
- Type-C Connectivity: Features a reversible Type-C port for modern and convenient power input.
- Integrated Safety Protection: Protects against battery overcharge, over-discharge, and short-circuit conditions.
- High Efficiency: Delivers stable power conversion with minimal energy loss during operation.
- Compact Design: Small PCB footprint allows easy integration into tight enclosures and DIY builds.
How to Use / Working Guide
Connect your single-cell 3.7V lithium battery to the designated B+ and B- terminals, ensuring correct polarity. The output terminals VO+ and VO- provide a regulated 5V supply for your load or device. Connect a standard Type-C charger to the input port to recharge the connected battery safely. Always verify connections before powering on.
Applications & Ideal Use Cases
- Building custom DIY power banks
- Portable USB-powered Arduino projects
- Emergency LED lighting power supplies
- Upgrading old battery-operated electronics
Frequently Asked Questions (FAQ)
Q: Can this module charge and discharge at the same time?
A: This module is primarily designed for standard charging and boosting sequences; simultaneous charge-discharge depends on the specific circuit variant and load current.
Q: What type of battery is compatible with this board?
A: It is designed for standard 3.7V to 4.2V lithium-ion or lithium-polymer (LiPo) rechargeable batteries.
Package Includes
- 1 x Type-C 5V Step-Up Boost Lithium Battery Charging and Discharging Protection Board
